Gigabyte Z890 AORUS MASTER Motherboard – 10GbE LAN – WiFi 7 – DDR5 – LGA 1851 – ATX

1 / 2

Gigabyte Z890 AORUS MASTER Motherboard – 10GbE LAN – WiFi 7 – DDR5 – LGA 1851 – ATX

2,550.00 NIS

⚙️

Intel® 15th Gen • LGA1851

🚀

Up to 9500MHz • 4 Slots

🚀

PCIe 5.0 Graphics Support

⚡

Ultra-Fast Data & Display Output

Description

The Gigabyte Z890 AORUS MASTER WiFi 7 motherboard is a flagship platform built for next-generation Intel Core Ultra processors. Featuring ultra-fast 10GbE LAN, cutting-edge WiFi 7 connectivity, and high-speed DDR5 support, it delivers uncompromising performance, stability, and connectivity for elite gaming and professional workstation builds.

✓

Intel® Z890 Chipset for Core Ultra (Series 2) CPUs
✓

Next-Generation WiFi 7 & Bluetooth Connectivity
✓

Ultra-Fast 10GbE LAN for Professional Networking
✓

DDR5 Memory Support for Extreme Performance
✓

Flagship AORUS MASTER ATX Design with Extreme Power Delivery

• Brand: Gigabyte
• Model: Z890 AORUS MASTER
• Product Code (P/N): Z890 AORUS MASTER
• Condition: New
• Form Factor: ATX

• CPU Socket: LGA 1851
• Chipset: Intel® Z890
• Supported CPUs: Intel® 15th Gen Arrow Lake

• Memory:
- Type: DDR5
- Slots: 4x DIMM
- Max Speed: Up to 9500MHz (OC)

• Expansion Slots:
- 1x PCIe 5.0 x16
- 2x PCIe 4.0 x16 (running at x4 / x1)

• Graphics Interface: PCI Express 5.0 x16

• Display Outputs:
- 2x Intel® Thunderbolt™ 4 (USB4 Type-C)
(Supports DisplayPort & Thunderbolt™)
• Multi-Display Support: Up to 2 Displays

• Audio:
- Realtek® ALC1220-VB Audio CODEC
- Optical Audio Output

• Storage:
- 4x SATA III
- 2x NVMe PCIe Gen5 M.2 (x4/x2)
- 3x NVMe PCIe 4.0 / 3.0 M.2

• USB & Connectivity:
- 2x Thunderbolt™ 4 / USB4 Type-C
- USB 3.2 Type-C
- USB 3.2 Gen1 Type-A
- USB 2.0 Type-A: 4
- USB 2.0 Headers: 2
- Front USB 3.2 Gen2 Type-C Header

• Wireless:
- Intel® Wi-Fi 7 (BE200NGW)
- Bluetooth 5.4

• LAN:
- Marvell® AQtion AQC113C 10GbE Ethernet
(10G / 5G / 2.5G / 1G / 100M)

• RAID Support: RAID 0 / 1 / 5 / 10
• Fan Headers: 4x System Fan Headers
• Q-Flash: Supported
• Operating System: Windows 11 (64-bit)
• Warranty: 3 Years
