Gigabyte Z890 AERO D Motherboard – Dual 10Gb LAN – WiFi 7 – DDR5 – LGA 1851 – ATX

• Brand: Gigabyte
• Model: Z890 AERO D
• Product Code (P/N): Z890 AERO D
• Condition: New
• Form Factor: ATX

• CPU Socket: LGA 1851
• Chipset: Intel® Z890
• Supported CPUs: Intel® 15th Gen Arrow Lake

• Memory:
- Type: DDR5
- Slots: 4x DIMM
- Max Speed: Up to 9500MHz (OC)

• Expansion Slots:
- 1x PCIe 5.0 x16
- 1x PCIe 4.0 x16 (running at x8)
- 1x PCIe 4.0 x16 (running at x4)

• Graphics Interface: PCI Express 5.0 x16

• Display Outputs:
- 2x Thunderbolt™ 4 (USB4 Type-C, DisplayPort support)
- 1x HDMI
- 1x DisplayPort
• Multi-Display Support: Up to 4 Displays

• Audio:
- Realtek® High-Definition Audio CODEC

• Storage:
- 4x SATA III
- 1x NVMe PCIe Gen5 M.2 (x4/x2)
- 3x NVMe PCIe 4.0 / 3.0 M.2

• USB & Connectivity:
- 2x Thunderbolt™ 4 / USB4 Type-C
- 2x USB4 Type-C with DisplayPort
- 2x USB 3.2 Type-C
- USB 3.0 Headers: 2
- USB 2.0 Headers: 2
- Front USB 3.2 Gen2 Type-C Header
- Internal Thunderbolt Header: 1

• Wireless:
- Intel® Wi-Fi 7 (BE200)
- Bluetooth 5.4

• LAN:
- Marvell® AQtion AQC113C Dual 10GbE Ethernet
(10G / 5G / 2.5G / 1G / 100M)

• RAID Support: RAID 0 / 1 / 5 / 10
• Fan Headers: 7x System Fan Headers
• Q-Flash: Supported
• Operating System: Windows 10 / 11 (64-bit)
• Warranty: 3 Years
